Page 0006

View our

Hospitality case study,

Charlton Hall

In the ceremony hall, an

unusual art deco floor design

has been hand cut from

Opus Luna and Nero, and

partnered with a romantic

floral canopy suspended from

the ceiling, decorative lights

and contemporary acrylic

chairs. Keen to continue

a quirky geometric theme

throughout the wedding venue,

the dining and bar areas also

feature a spectacular bespoke

monochrome design, uplifted

with bright pink chair cushions.

Charlton Hall, Northumberland

"It was absolutely essential the floor was both luxurious and slightly off the wall,"

- Richard Shell, owner of Charlton Hall

Products specified:

Standard Art Select Result Van Gogh Result

Size EN ISO 24342

406.4 mm x 406.4 mm and 457.2 mm x 609.6 mm

914.4mm x 914.4mm

1219.2 mm x 177.8 mm

Thickness EN ISO 24346 3.0 mm 3.0 mm

Wear layer EN ISO 24340 0.7 mm 0.55 mm

Guarantee Light industrial

Commercial

Residential

20 years*

20 years*

Lifetime guarantee*

15 years*

15 years*

Lifetime guarantee*

Bevelled edge Standard Micro

Art Select

Notifi ed body 0321

Floor coverings (internal)

17

EN 14041: 2004 (DOP 2017/AS/EN/01)

ISO 10874 Class 23/34/43

Manufactured to ISO 10582

* Subject to terms. Please speak to your Commercial Specification Manager for more information.

Van Gogh

Notifi ed body 0321

Floor coverings (internal)

17

EN 14041: 2004 (DOP 2017/VG/EN/01)

ISO 10874 Class 23/33/42

Manufactured to ISO 10582

Manufactured

to ISO 9001

To view the full technical specification for each of our product ranges

visit our website:

karndean.com/commercialtechdata

Standard Result Product Size (mm) LRV

Size EN ISO 24342 1219.2 mm x 177.8 mm VG1-7 1219.2 X 177.8(48"x7") 14

Thickness EN ISO 24346 3.0 mm VG5-7 1219.2 X 177.8(48"x7") 17

Wear layer EN ISO 24340 0.55 mm VGW44T 1219.2 X 177.8(48"x7") 23

Surface treatment K-Guard+ PU coating VGW50T 1219.2 X 177.8(48"x7") 40

Mass EN ISO 23997 5187 g/m

2 VGW52T 1219.2 X 177.8(48"x7") 25

Guarantee Light industrial 15 years* VGW53T 1219.2 X 177.8(48"x7") 22

Commercial 15 years* VGW54T 1219.2 X 177.8(48"x7") 10

Residential Lifetime quarantee* VGW70T 1219.2 X 177.8(48"x7") 12

Bevelled edge Micro VGW71T 1219.2 X 177.8(48"x7") 32

Standards EN 649/ EN ISO 10582 Pass VGW76T 1219.2 X 177.8(48"x7") 19

Classification EN 685/ EN ISO 10874- Light industrial 42: Light industrial general VGW80T 1219.2 X 177.8(48"x7") 56

EN 685/EN ISO 10874- Commercial 33: Commercial heavy VGW81T 1219.2 X 177.8(48"x7") 32

EN 685/EN ISO 10874- Domestic 23: Domestic heavy VGW82T 1219.2 X 177.8(48"x7") 29

Reaction to fire EN 13501-1 Bfl-s1 VGW83T 1219.2 X 177.8(48"x7") 33

Staining resistance EN ISO 26987/EN 423 Excellent VGW84T 1219.2 X 177.8(48"x7") 24

Light fastness EN ISO 105-B02 ≥7 VGW85T 1219.2 X 177.8(48"x7") 35

Abrasion resistance EN 660-2 Group T VGW86T 1219.2 X 177.8(48"x7") 28

EN ISO 10582 Type 1 VGW87T 1219.2 X 177.8(48"x7") 14

Flexibility EN ISO 24344 Pass VGW88T 1219.2 X 177.8(48"x7") 14

Dimensional stability EN 434/ EN ISO 23999 ≤ 0.25% VGW89T 1219.2 X 177.8(48"x7") 8

Acoustic Impact noise reduction EN ISO 717-2 / EN ISO 140-8 ΔLw= 4 dB VGW91T 1219.2 X 177.8(48"x7") 9

Electrical behaviour body voltage EN 1815 Pass VGW93T 1219.2 X 177.8(48"x7") 18

Indentation - residual EN 433/EN ISO 24343-1 Pass ≤ 0.1mm VGW94T 1219.2 X 177.8(48"x7") 28

Castor chair continuous use EN 425/ ISO 4918 Pass VGW99T 1219.2 X 177.8(48"x7") 18

Thermal resistance ISO 8302 0.0147 m²K/W VGW100T 1219.2 X 177.8(48"x7") 27

Suitable for underfloor heating.

Max 27o

C

VGW102T 1219.2 X 177.8(48"x7") 8

Slip resistance** DIN 51130 R10 VGW107T 1219.2 X 177.8 (48"x7") 50

EN 13893 DS VGW110T 1219.2 X 177.8 (48"x7") 33

Light reflectance value (LRV) BS 8493:2008+A1:2010 See separate table VGW111T 1219.2 X 177.8 (48"x7") 43

VOC emission ISO 16000 Indoor Air Comfort Gold VGW112T 1219.2 X 177.8 (48"x7") 28

Adhesive Karndean Universal Yes VGW113T 1219.2 X 177.8 (48"x7") 34

Acrylic Yes VGW115T 1219.2 X 177.8 (48"x7") 35

Epoxy Yes

High Temperature Yes

Pressure sensitive Yes

Recycling Suitable

Phthalate free Yes

*Subject to terms. Please see our website.

For more information:

Call: 01386 820104 For ROI call: 01 6569887

Email: commercial@karndean.co.uk

Visit: www.karndean.com

8/19

Technical Data

** Slip resistance is measured on freestanding ex-factory product. Slip resistance can be affected by many factors, including but not limited to; product installation and

underlayment, surface contamination, use, wear and how the product is maintained. Textural variation along the surface of the product can affect nominal values.

Manufactured to ISO9001

Standard Result Product Size (mm) LRV

Size EN ISO 24342 See separate table CC04 406.4 x 406.4 (16"x16") 75

Thickness EN ISO 24346 3.0 mm CC06 406.4 x 406.4 (16"x16") 14

Wear layer EN ISO 24340 0.7 mm CER11 304.8 X 457.2(12"x18") 11

Surface treatment K-Guard+ PU coating CER12 304.8 X 457.2(12"x18") 9

Mass EN ISO 23997 5015 g/m2 CER13 304.8 X 457.2(12"x18") 9

Guarantee Light industrial 20 years* CER14 304.8 X 457.2(12"x18") 9

Commercial 20 years* CER15 304.8 X 457.2(12"x18") 35

Residential Lifetime guarantee* CER16 304.8 X 457.2(12"x18") 21

Bevelled edge Standard CER17 304.8 X 457.2(12"x18") 21

Standards EN 649/ ISO 10582 Pass CER18 304.8 X 457.2(12"x18") 53

Classification EN 685/ EN ISO 10874- Light industrial 43: Light industrial heavy CER19 304.8 X 457.2(12"x18") 19

EN 685/EN ISO 10874- Commercial 34: Commercial very heavy CER20 304.8 X 457.2(12"x18") 31

EN 685/EN ISO 10874- Domestic 23: Domestic heavy CER21 304.8 X 457.2(12"x18") 12

Reaction to fire EN 13501-1 Bfl-s1 CK25 406.4 x 406.4 (16"x16") 8

Staining resistance EN ISO 26987/EN 423 Excellent LST02 406.4 x 406.4 (16"x16") 53

Light fastness EN ISO 105-B02 ≥6 LST03 406.4 x 406.4 (16"x16") 49

Abrasion resistance EN 649 Group T LST04 406.4 x 406.4 (16"x16") 40

EN ISO 10582 Type 1 LST05 406.4 x 406.4 (16"x16") 26

Flexibility EN ISO 24344 Pass RP11 914.4 X 76.2(36"x3") 37

Dimensional stability EN 434/ EN ISO 23999 Pass RP41 914.4 X 76.2(36"x3") 8

Acoustic Impact noise reduction EN ISO 717-2 / EN ISO 140-8 ΔLw= 2 dB RP73 914.4 X 76.2(36"x3") 20

Electrical behaviour body voltage EN 1815 Pass RP90 914.4 X 76.2(36"x3") 25

Indentation - residual EN 433/EN ISO 24343-1 Pass ≤ 0.1mm RP91 914.4 X 76.2(36"x3") 17

Castor chair continuous use EN 425/ ISO 4918 Pass RP92 914.4 X 76.2(36"x3") 13

Thermal resistance ISO 8302 0.0147 m²K/W RP94 914.4 X 76.2(36"x3") 10

Suitable for underfloor heating.

Max 27oC

RP95 914.4 X 76.2(36"x3") 12

Slip resistance** DIN 51130 R10 RP96 914.4 X 76.2(36"x3") 22

EN 13893 DS RP97 914.4 X 76.2(36"x3") 19

Light reflectance value (LRV) BS 8493:2008+A1:2010 See separate table RP98 914.4 X 76.2(36"x3") 25

VOC emission ISO 16000 Indoor Air Comfort Gold RP99 914.4 X 76.2(36"x3") 13

Adhesive Karndean Universal Yes RP100 914.4 X 76.2(36"x3") 17

Acrylic Yes RP101 914.4 X 76.2(36"x3") 12

Epoxy Yes RP102 914.4 X 76.2(36"x3") 28

High Temperature Yes RP103 914.4 X 76.2(36"x3") 26

Pressure sensitive Yes RP104 914.4 X 76.2(36"x3") 13

Recycling Suitable RP105 914.4 X 76.2(36"x3") 9

Phthalate free Yes

*Subject to terms. Please see our website.

commercial@karndean.co.uk

Call: 01386 820104 For ROI call: 01 6569887

Email: commercial@karndean.co.uk

Visit: www.karndean.com

08/19

Technical Data

** Slip resistance is measured on freestanding ex-factory product. Slip resistance can be affected by many factors, including but not limited to; product installation and

underlayment, surface contamination, use, wear and how the product is maintained. Textural variation along the surface of the product can affect nominal values.

Manufactured to ISO9001

Standard Result Product Size (mm) LRV

Size EN ISO 24342 See separate table AP01 228.6 X 76.2 (9"x3") 27

Thickness EN ISO 24346 3.0 mm AP02 228.6 X 76.2 (9"x3") 14

Wear layer EN ISO 24340 0.7 mm AP03 228.6 X 76.2 (9"x3") 6

Surface treatment K-Guard+ PU coating AP04 228.6 X 76.2 (9"x3") 10

Guarantee Light industrial 20 years* AP05 228.6 X 76.2 (9"x3") 9

Commercial 20 years* AP06 228.6 X 76.2 (9"x3") 16

Residential Lifetime guarantee* AP07 228.6 X 76.2 (9"x3") 27

Bevelled edge Standard AP31 406.4 X 406.4 (16"x16") 14

Mass EN ISO 23997 5015 g/m

2 EW01 914.4 X 152.4 (36"x6") 14

Standards EN 649/EN ISO 10582 Pass EW02 914.4 X 152.4 (36"x6") 9

Classification EN 685/EN ISO 10874- Light industrial 43: Light industrial heavy EW03 914.4 X 152.4 (36"x6") 12

EN 685/EN ISO 10874- Commercial 34: Commercial very heavy EW10 1422.4 X 228.6 ( 56"x9") 36

EN 685/EN ISO 10874- Domestic 23: Domestic heavy EW11 1422.4 X 228.6 (56"x9") 33

Reaction to fire EN 13501-1 Bfl-s1 EW12 1422.4 X 228.6 (56"x9") 25

Staining resistance EN ISO 26987/EN 423 Excellent EW13 1422.4 X 228.6 (56"x9") 33

Light fastness EN ISO 105-B02 ≥6 EW21 1422.4 X 228.6 (56"x9") 15

Abrasion resistance EN 649 Group T RPL-EW21

114.3, 152.4, 228.6

(4.5", 6", 9") widths in

various lengths

15

EN ISO 10582 Type 1 HC01 914.4 X 152.4 (36"x6") 14

Flexibility EN ISO 24344 Pass HC02 914.4 X 152.4 (36"x6") 16

Dimensional stability EN 434/EN ISO 23999 Pass HC03 914.4 X 152.4 (36"x6") 17

Acoustic Impact noise reduction EN ISO 717-2 / EN ISO 140-8 ΔLw= 2 dB HC04 914.4 X 152.4 (36"x6") 10

Electrical behaviour body voltage EN 1815 Pass HC05 914.4 X 152.4 (36"x6") 8

Indentation - residual EN 433/ EN ISO 24343-1 Pass ≤ 0.1mm HC06 914.4 X 152.4 (36"x6") 6

Castor chair continuous use EN 425/ ISO 4918 Pass LM01 49

Thermal resistance ISO 8302 0.0147 m

2K/W LM02 35

Suitable for underfloor heating.

Max 27o

C

LM03 59

Slip resistance** DIN 51130 R10 / R11*** LM10 10

EN 13893 DS LM11 17

Light reflectance value (LRV) BS 8493:2008+A1:2010 See separate table LM12 21

VOC emission ISO 16000 Indoor Air Comfort Gold LM20 13

Adhesive Karndean Universal Yes LM05 609.6 X 457.2 (24"x18") 18

Acrylic Yes LM06 609.6 X 457.2 (24"x18") 10

Epoxy Yes LM07 609.6 X 457.2 (24"x18") 49

High Temperature Yes LM08 609.6 X 457.2 (24"x18") 31

Pressure sensitive Yes LM09 609.6 X 457.2 (24"x18") 42

Recycling Suitable LM15 406.4 X 406.4 (16"x16") 19

Phthalate free Yes LM15-CLIP 406.4 X 406.4 (16"x16") 19

* Subject to terms. Please see our website. LM16 406.4 X 406.4 (16"x16") 61

LM16-CLIP 406.4 X 406.4 (16"x16") 61

LM21 609.6 X 457.2 (24"x18") 21

**** Offsetting tiles are also included to create a natural look

LM22 609.6 X 457.2 (24"x18") 17

LM27 914.4 X 152.4 (36"x6") 49

commercial@karndean.co.ukLM28 914.4 X 152.4 (36"x6") 31

Call: 01386 820104 For ROI call: 01 6569887 LM29 914.4 X 152.4 (36"x6") 42

Email: commercial@karndean.co.uk RL01 1219.2 X 177.8 (48"x7") 27

Visit: www.karndean.com RL02 1219.2 X 177.8 (48"x7") 20

RL03 1219.2 X 177.8 (48"x7") 14

RL04 1219.2 X 177.8 (48"x7") 8

Manufactured to ISO9001 RL05 1219.2 X 177.8 (48"x7") 9

RL07 1219.2 X 177.8 (48"x7") 9

RL12 1219.2 X 177.8 (48"x7") 27

RL20 1422.4 X 228.6 (56"x9") 29

RL21 1422.4 X 228.6 (56"x9") 41

08/19

RL22 1422.4 X 228.6 (56"x9") 41

RL23 1422.4 X 228.6 (56"x9") 41

SBW-RL01

304.8 X 76.2 (12"x3") and

114.3 x 114.3 (4.5"x4.5")

27

SBW-RL12

304.8 X 76.2 (12"x3") and

114.3 x 114.3 (4.5"x4.5")

27

SM-RL20 457.2 x 76.2mm (18"x3") 29

SM-RL21 457.2 x 76.2mm (18"x3") 41

SM-RL22 457.2 x 76.2mm (18"x3") 41

SM-RL23 457.2 x 76.2mm (18"x3") 41

Each panel is created from

nine assorted tiles with

design strips****:-

457.2 X 457.2 (18"x18")

457.2 X 304.8 (18"x12")

457.2 X 152.4 (18"x6")

304.8 X 304.8 (12"x12")

304.8 X 152.4 (12"x6")

152.4 X 152.4 (6"x6")

** Slip resistance is measured on freestanding ex-factory product. Slip resistance can be affected by many factors, including but not limited to; product

installation and underlayment, surface contamination, use, wear and how the product is maintained. Textural variation along the surface of the product can

affect nominal values.

*** DIN51130 slip resistance values have achieved R10 except EW21, RPL-EW21, RL20, RL21, RL22, RL23, SM-RL20, SM-RL21, SM-RL22, SM-RL23 which have

achieved R11. All R11 SKUs also achieve >36 to BS7976

Technical Data
